Description
Technical Specifications
- Voltage: AC100~250V/AC, 50HZ/60HZ
- Rated Power: 700W
- Waterproof Level: IP65
- Work Environment: Outdoor and indoor, -30°C ~40°C
- Scanner: Highest quality optical scanner, high speed and high precision, high stability and long-life design. >35KPPS ILDA @8°. Max scanning angle is 50°. Signal input voltage ±5V
- Laser Source: RGB analog module, 30KHZ frequency
- Laser Power / Wavelength (30W): Red 8W (638nm) / Green 10W (525nm) / Blue 15W (450nm)
- Laser Power / Wavelength (40W): Red 12W (638nm) / Green 15W (525nm) / Blue 18W (450nm)
- Laser Power / Wavelength (60W): Red 16W (638nm) / Green 20W (525nm) / Blue 28W (450nm)
- Beam Diameter: <7.0mm
- Divergence: <1.5mrad
- Laser Level: Class 4 laser
- Laser Life: >10000 hours
- Working Modes: BEYOND/Quick Show, ILDA, DMX-512, Art NET, Autoplay
- Graphics & Effects: Beam show and animated graphics show patterns
- TF Card: 32GB, built in programs, and downloading program
- Play Program Format: FB4 laser show document downloading for BEYOND/QS
- Safety Features: Security protection, Laser key switch, laser remote interlock, SFS Control (scanner fail safety control ON/OFF), eye bolt for safety cable attachment
- Interface: RJ45 Ethernet LAN port for BEYOND/Quick Show, 3 pin XLR jack for DMX, RJ45-ILDA interface for PC control (RJ45 cat5/cat6 cable is more widely available than ILDA cables and there is no signal loss even after 300 meters transmission) RJ45 to ILDA adapters sold separately (NOT INCLUDED)
- Machine Dimensions (30W/40W): 465(L) x 320(W) x 220(H)mm / 18.3 x 12.6″ x 8.7″
- Machine Dimensions (60W): 570(L) x 350(W) x 230(H)mm / 22.4″ x 13.8″ x 9″
- Fixture Weight: 30W/40W 28Kg (62lb) / 60W 35Kg (77lb)
- Flight Case Dimensions (30W/40W): 620 x 471 x 387mm
